博客作者:凌逆戰
博客地址:https://www.cnblogs.com/LXP-Never/p/12774058.html
文章代碼:https://github.com/LXP-Never/blog_data/tree/master/tensorflow_model
我一直覺得TensorFlow的深度神經網絡代碼非常困難且繁瑣,對TensorFlow搭建模型也十分困惑,所以我近期閱讀了大量的神經網絡代碼,終於找到了搭建神經網絡的規律,各位要是覺得我的文章對你有幫助不妨點個贊,點個關注吧。
我個人把深度學習分為以下步驟:數據處理 –> 模型搭建 –> 構建損失 –> 模型訓練 –> 模型評估
我先把代碼放出來,然後一點一點來講
# Author:凌逆戰
# -*- encoding:utf-8 -*-
# 修改時間:2020年5月31日
import time
from tensorflow.examples.tutorials.mnist import input_data
from nets.my_alex import alexNet
from ops import *
tf.flags.DEFINE_integer('batch_size', 50, 'batch size, default: 1')
tf.flags.DEFINE_integer('class_num', 10, 'batch size, default: 1')
tf.flags.DEFINE_integer('epochs', 10, 'batch size, default: 1')
tf.flags.DEFINE_float('learning_rate', 1e-4, '初始學習率, 默認: 0.0002')
tf.flags.DEFINE_string('checkpoints_dir', "checkpoints", '保存檢查點的地址')
FLAGS = tf.flags.FLAGS
# 從MNIST_data/中讀取MNIST數據。當數據不存在時,會自動執行下載
mnist = input_data.read_data_sets('./data', one_hot=True, reshape=False)
# reshape=False (None, 28,28,1) # 用於第一層是卷積層
# reshape=False (None, 784) # 用於第一層是全連接層
# 我們看一下數據的shape
print(mnist.train.images.shape) # 訓練數據圖片(55000, 28, 28, 1)
print(mnist.train.labels.shape) # 訓練數據標籤(55000, 10)
print(mnist.test.images.shape) # 測試數據圖片(10000, 28, 28, 1)
print(mnist.test.labels.shape) # 測試數據圖片(10000, 10)
print(mnist.validation.images.shape) # 驗證數據圖片(5000, 28, 28, 1)
print(mnist.validation.labels.shape) # 驗證數據圖片(5000, 784)
def train():
batch_size = FLAGS.batch_size # 一個batch訓練多少個樣本
batch_nums = mnist.train.images.shape[0] // batch_size # 一個epoch中應該包含多少batch數據
class_num = FLAGS.class_num # 分類類別數
epochs = FLAGS.epochs # 訓練周期數
learning_rate = FLAGS.learning_rate # 初始學習率
############ 保存檢查點的地址 ############
checkpoints_dir = FLAGS.checkpoints_dir # checkpoints
# 如果檢查點不存在,則創建
if not os.path.exists(checkpoints_dir):
os.makedirs(FLAGS.checkpoints_dir)
######################################################
# 創建圖 #
######################################################
graph = tf.Graph() # 自定義圖
# 在自己的圖中定義數據和操作
with graph.as_default():
inputs = tf.placeholder(dtype="float", shape=[None, 28, 28, 1], name='inputs')
labels = tf.placeholder(dtype="float", shape=[None, class_num], name='labels')
# 看個人喜歡,有的人在初始化定義中就定義了learning_rate,有的人喜歡通過feed傳learning_rate
learning_rate = tf.placeholder("float", None, name='learning_rate')
# 如果網絡結構有dropout層,需要定義keep_probn,如果沒有則不需要
# 訓練的時候需要,測試的時候需要設置成1
keep_prob = tf.placeholder(dtype="float", name='keep_prob')
############ 搭建模型 ############
logits = alexNet(inputs, class_num, keep_prob=keep_prob) # 使用placeholder搭建模型
############ 損失函數 ############
loss = tf.reduce_mean(tf.nn.softmax_cross_entropy_with_logits(labels=labels, logits=logits))
tf.add_to_collection('losses', loss)
total_loss = tf.add_n(tf.get_collection("losses")) # total_loss=模型損失+權重正則化損失
############ 模型精度 ############
predict = tf.argmax(logits, 1) # 模型預測結果
accuracy = tf.reduce_mean(tf.cast(tf.equal(predict, tf.argmax(labels, 1)), tf.float32))
############ 優化器 ############
variable_to_train = tf.get_collection(tf.GraphKeys.TRAINABLE_VARIABLES) # 可訓練變量列表
# 創建優化器,更新網絡參數,最小化loss,
global_step = tf.Variable(0, trainable=False)
learning_rate = tf.train.exponential_decay(learning_rate=learning_rate, # 初始學習率
global_step=global_step,
decay_steps=batch_nums, # 多少步衰減一次
decay_rate=0.1, # 衰減率
staircase=True) # 以階梯的形式衰減
# 移動平均值更新參數
# train_op = moving_average(loss, learning_rate, global_step)
# adam優化器,adam算法好像會自動衰減學習率,
train_op = tf.train.AdamOptimizer(learning_rate).minimize(loss=total_loss,
global_step=global_step,
var_list=variable_to_train)
############ TensorBoard可視化 summary ############
summary_writer = tf.summary.FileWriter(logdir="./logs", graph=graph) # 創建事件文件
tf.summary.scalar(name="losses", tensor=total_loss) # 收集損失值變量
tf.summary.scalar(name="acc", tensor=accuracy) # 收集精度值變量
tf.summary.scalar(name='learning_rate', tensor=learning_rate)
merged_summary_op = tf.summary.merge_all() # 將所有的summary合併為一個op
############ 模型保存和恢復 Saver ############
saver = tf.train.Saver(max_to_keep=5)
######################################################
# 創建會話 #
######################################################
max_acc = 0.
config = tf.ConfigProto(allow_soft_placement=True, log_device_placement=True)
with tf.Session(config=config, graph=graph) as sess:
# 加載模型,如果模型存在返回 是否加載成功和訓練步數
could_load, checkpoint_step = load_model(sess, saver, FLAGS.checkpoints_dir)
if could_load:
print(" [*] 模型加載成功")
else:
print(" [!] 模型加載失敗")
try:
tf.global_variables_initializer().run()
except:
tf.initialize_all_variables().run()
for epoch in range(epochs):
for i in range(batch_nums):
start_time = time.time()
# batch_images = data_X[i * batch_size:(i + 1) * batch_size]
# batch_labels = data_y[i * batch_size:(i + 1) * batch_size]
train_batch_x, train_batch_y = mnist.train.next_batch(batch_size)
# 使用真實數據填充placeholder,運行訓練模型和合併變量操作
_, summary, loss, step = sess.run([train_op, merged_summary_op, total_loss, global_step],
feed_dict={inputs: train_batch_x,
labels: train_batch_y,
keep_prob: 0.5})
if step % 100 == 0:
summary_writer.add_summary(summary, step) # 將每次迭代后的變量寫入事件文件
summary_writer.flush() # 強制summary_writer將緩存中的數據寫入到日誌文件中(可選)
############ 可視化打印 ############
print("Epoch:[%2d] [%4d/%4d] time:%4.4f,loss:%.8f" % (
epoch, i, batch_nums, time.time() - start_time, loss))
# 打印一些可視化的數據,損失...
if step % 100 == 0:
acc = sess.run(accuracy, feed_dict={inputs: mnist.validation.images,
labels: mnist.validation.labels,
keep_prob: 1.0})
print("Epoch:[%2d] [%4d/%4d] accuracy:%.8f" % (epoch, i, batch_nums, acc))
############ 保存模型 ############
if acc > max_acc:
max_acc = acc
save_path = saver.save(sess,
save_path=os.path.join(checkpoints_dir, "model.ckpt"),
global_step=step)
tf.logging.info("模型保存在: %s" % save_path)
print("優化完成!")
def main(argv=None):
train()
if __name__ == '__main__':
# logging.basicConfig(level=logging.INFO)
tf.logging.set_verbosity(tf.logging.INFO)
tf.app.run()
main(global_step)
# Author:凌逆戰
# -*- encoding:utf-8 -*-
# 修改時間:2020年5月31日
import time
from tensorflow.examples.tutorials.mnist import input_data
from nets.my_vgg import VGG16Net
from ops import *
tf.flags.DEFINE_integer('batch_size', 100, 'batch size, default: 1')
tf.flags.DEFINE_integer('class_num', 10, 'batch size, default: 1')
tf.flags.DEFINE_integer('epochs', 10, 'batch size, default: 1')
tf.flags.DEFINE_float('learning_rate', 2e-4, '初始學習率, 默認: 0.0001')
tf.flags.DEFINE_string('checkpoints_dir', "checkpoint", '保存檢查點的地址')
FLAGS = tf.flags.FLAGS
# 從MNIST_data/中讀取MNIST數據。當數據不存在時,會自動執行下載
mnist = input_data.read_data_sets('./MNIST_data', one_hot=True, reshape=False)
# reshape=False (None, 28,28,1) # 用於第一層是卷積層
# reshape=False (None, 784) # 用於第一層是全連接層
# 我們看一下數據的shape
print(mnist.train.images.shape) # 訓練數據圖片(55000, 28, 28, 1)
print(mnist.train.labels.shape) # 訓練數據標籤(55000, 10)
print(mnist.test.images.shape) # 測試數據圖片(10000, 28, 28, 1)
print(mnist.test.labels.shape) # 測試數據圖片(10000, 10)
print(mnist.validation.images.shape) # 驗證數據圖片(5000, 28, 28, 1)
print(mnist.validation.labels.shape) # 驗證數據圖片(5000, 784)
def train():
batch_size = FLAGS.batch_size
batch_nums = mnist.train.images.shape[0] // batch_size # 一個epoch中應該包含多少batch數據
class_num = FLAGS.class_num
epochs = FLAGS.epochs
learning_rate = FLAGS.learning_rate
############ 保存檢查點的地址 ############
checkpoints_dir = FLAGS.checkpoints_dir # checkpoints
# 如果檢查點不存在,則創建
if not os.path.exists(checkpoints_dir):
os.makedirs(FLAGS.checkpoints_dir)
######################################################
# 創建圖 #
######################################################
graph = tf.Graph() # 自定義圖
# 在自己的圖中定義數據和操作
with graph.as_default():
inputs = tf.placeholder(dtype="float", shape=[None, 28, 28, 1], name='inputs')
labels = tf.placeholder(dtype="float", shape=[None, class_num], name='labels')
############ 搭建模型 ############
logits = VGG16Net(inputs, class_num) # 使用placeholder搭建模型
############ 損失函數 ############
# 計算預測值和真實值之間的誤差
loss = tf.reduce_mean(tf.nn.softmax_cross_entropy_with_logits(labels=labels, logits=logits))
tf.add_to_collection('losses', loss)
total_loss = tf.add_n(tf.get_collection("losses")) # total_loss=模型損失+權重正則化損失
############ 模型精度 ############
predict = tf.argmax(logits, axis=1)
accuracy = tf.reduce_mean(tf.cast(tf.equal(predict, tf.argmax(labels, axis=1)), tf.float32))
############ 優化器 ############
variable_to_train = tf.get_collection(tf.GraphKeys.TRAINABLE_VARIABLES) # 可訓練變量列表
# 創建優化器,更新網絡參數,最小化loss,
train_op = tf.train.AdamOptimizer(learning_rate).minimize(loss=total_loss,
var_list=variable_to_train)
############ TensorBoard可視化 summary ############
summary_writer = tf.summary.FileWriter("./logs", graph=graph) # 創建事件文件
tf.summary.scalar(name="loss", tensor=total_loss) # 收集損失值變量
tf.summary.scalar(name='accuracy', tensor=accuracy) # 收集精度值變量
tf.summary.scalar(name='learning_rate', tensor=learning_rate)
merged_summary_op = tf.summary.merge_all() # 將所有的summary合併為一個op
############ 模型保存和恢復 Saver ############
saver = tf.train.Saver(max_to_keep=5)
######################################################
# 創建會話 #
######################################################
max_acc = 0.
config = tf.ConfigProto(allow_soft_placement=True, log_device_placement=True)
with tf.Session(config=config, graph=graph) as sess:
# 加載模型,如果模型存在返回 是否加載成功和訓練步數
could_load, checkpoint_step = load_model(sess, saver, FLAGS.checkpoints_dir)
if could_load:
step = checkpoint_step
print(" [*] 模型加載成功")
else:
print(" [!] 模型加載失敗")
try:
tf.global_variables_initializer().run()
except:
tf.initialize_all_variables().run()
step = 0
for epoch in range(epochs):
for i in range(batch_nums):
start_time = time.time() # 記錄一下開始訓練的時間
# batch_images = data_X[i * batch_size:(i + 1) * batch_size]
# batch_labels = data_y[i * batch_size:(i + 1) * batch_size]
train_batch_x, train_batch_y = mnist.train.next_batch(batch_size)
# 使用真實數據填充placeholder,運行訓練模型和合併變量操作
_, summary, loss = sess.run([train_op, merged_summary_op, total_loss],
feed_dict={inputs: train_batch_x,
labels: train_batch_y})
if step % 100 == 0:
summary_writer.add_summary(summary, step) # 將每次迭代后的變量寫入事件文件
summary_writer.flush() # 強制summary_writer將緩存中的數據寫入到日誌文件中(可選)
############ 可視化打印 ############
print("Epoch:[%2d] [%4d/%4d] time:%4.4f,loss:%.8f" % (
epoch, i, batch_nums, time.time() - start_time, loss))
# 打印一些可視化的數據,損失...
# if np.mod(step, 100) == 1
if step % 100 == 0:
acc = sess.run(accuracy, {inputs: mnist.validation.images,
labels: mnist.validation.labels})
print("Epoch:[%2d] [%4d/%4d],acc:%.8f" % (epoch, i, batch_nums, acc))
############ 保存模型 ############
if acc > max_acc:
max_acc = acc
save_path = saver.save(sess,
save_path=os.path.join(checkpoints_dir, "model.ckpt"),
global_step=step)
# logging.info("模型保存在: %s" % save_path)
tf.logging.info("模型保存在: %s" % save_path)
step += 1
print("優化完成!")
def main(argv=None):
train()
if __name__ == '__main__':
# logging.basicConfig(level=logging.INFO)
tf.logging.set_verbosity(tf.logging.INFO)
tf.app.run()
main(step)
數據處理
數據處理因為每個專業領域的原因各不相同,而這不同點也是各位論文創新點的新方向。不同的我沒法講,但我總結了幾點相同的地方——batch數據生成。因為深度學習模型需要一個batch一個batch的喂數據進行訓練,所以我們的數據必須是batch的形式,這裏衍生了三點問題
- 通過代碼批量讀取數據,
- 如何生成batch數據:由於篇幅過長,實在有很多地方要介紹和詳述,我把這一塊內容移到了這篇文章《TensorFlow讀取數據的三種方法》中
- 數據的shape:我舉兩個例子讓大家理解:圖片數據為4維 (batch_size, height,width, channels),序列數據為3維 (batch_size, time_steps, input_size),
- 不同的shape處理方法不同,選擇神經網絡模型單元也不同。我會在後面細講
模型搭建
閱讀這一節我默認大家已經學會了數據的batch讀取了。
模型搭建這一步很像我們小時候玩的搭積木,我這裏以經典神經網絡模型VGG、Alex、ResNet、Google Inception Net為例講解,大家看代碼看多了也會很簡單的就找到,當然我是有一點私心的,我想把這些經典的網絡在這篇文章做一個tensorflow實現匯總,我細講第一個,大家可能看一個例子就懂了,看懂了就直接往下看,看不懂就多看幾個。
LeNet5模型
論文:1998_LeNet_Gradient-Based Learning Applied to Document Recognition
下面我們定義一個LeNet5模型,我們先定義需要用到的神經網絡單元,相同的代碼盡量封裝成函數的形式以節省代碼量和簡潔代碼
def conv(input, kernel_size, output_size, stride, init_bias=0.0, padding="SAME", name=None, wd=None):
input_size = input.shape[-1]
conv_weights = tf.get_variable(name='weights',
shape=[kernel_size, kernel_size, input_size, output_size],
initializer=tf.truncated_normal_initializer(stddev=0.1),
dtype=tf.float32)
conv_biases = tf.get_variable(name='biases',
shape=[output_size],
initializer=tf.constant_initializer(init_bias),
dtype=tf.float32)
if wd is not None:
# wd 0.004
# tf.nn.l2_loss(var)=sum(t**2)/2
weight_decay = tf.multiply(tf.nn.l2_loss(conv_weights), wd, name='weight_loss')
tf.add_to_collection('losses', weight_decay)
conv_layer = tf.nn.conv2d(input, conv_weights, [1, stride, stride, 1], padding=padding, name=name) # 卷積操作
conv_layer = tf.nn.bias_add(conv_layer, conv_biases) # 加上偏置項
conv_layer = tf.nn.relu(conv_layer) # relu激活函數
return conv_layer
def fc(input, output_size, init_bias=0.0, activeation_func=True, wd=None):
input_shape = input.get_shape().as_list()
# 創建 全連接權重 變量
fc_weights = tf.get_variable(name="weights",
shape=[input_shape[-1], output_size],
initializer=tf.truncated_normal_initializer(stddev=0.1),
dtype=tf.float32)
if wd is not None:
# wd 0.004
# tf.nn.l2_loss(var)=sum(t**2)/2
weight_decay = tf.multiply(tf.nn.l2_loss(fc_weights), wd, name='weight_loss')
tf.add_to_collection('losses', weight_decay)
# 創建 全連接偏置 變量
fc_biases = tf.get_variable(name="biases",
shape=[output_size],
initializer=tf.constant_initializer(init_bias),
dtype=tf.float32)
fc_layer = tf.matmul(input, fc_weights) # 全連接計算
fc_layer = tf.nn.bias_add(fc_layer, fc_biases) # 加上偏置項
if activeation_func:
fc_layer = tf.nn.relu(fc_layer) # rele激活函數
return fc_layer
View Code
然後利用我們搭建的神經網絡單元,搭建LeNet5神經網絡模型
# 訓練時:keep_prob=0.5
# 測試時:keep_prob=1.0
def leNet(inputs, class_num, keep_prob=0.5):
# 第一層 卷積層 conv1
with tf.variable_scope('layer1-conv1'):
conv1 = conv(input=inputs, kernel_size=5, output_size=32, stride=1, init_bias=0.0, name="layer1-conv1",
padding="SAME")
# 第二層 池化層
with tf.name_scope('layer2-pool1'):
pool1 = tf.nn.max_pool(conv1, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME')
# 第三層 卷積層 conv2
with tf.variable_scope('layer3-conv2'):
conv2 = conv(input=pool1, kernel_size=5, output_size=64, stride=1, init_bias=0.0, name="layer3-conv2",
padding="SAME")
# 第四層 池化層
with tf.name_scope('layer4-pool2'):
pool2 = tf.nn.max_pool(conv2, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME')
# 後面要做全連接,因此要把數據變成2維
# pool_shape = pool2.get_shape().as_list()
pool_shape = pool2.shape
flatten = tf.reshape(pool2, [-1, pool_shape[1] * pool_shape[2] * pool_shape[3]])
with tf.variable_scope('layer5-fcl'):
fc1 = fc(input=flatten, output_size=512, init_bias=0.1, activeation_func=tf.nn.relu, wd=None)
fc1 = tf.nn.dropout(fc1, keep_prob=keep_prob, name="dropout1")
with tf.variable_scope('layer6-fc2'):
logit = fc(input=fc1, output_size=class_num, init_bias=0.1, activeation_func=False, wd=None)
return logit
Alex模型
論文:2012_Alex_ImageNet Classification with Deep Convolutional Neural Networks
下面我們定義一個Alex模型,我們先定義需要用到的神經網絡單元,相同的代碼盡量封裝成函數的形式以節省代碼量和簡潔代碼
def conv(input, kernel_size, output_size, stride, init_bias=0.0, padding="SAME", name=None, wd=None):
input_size = input.shape[-1]
conv_weights = tf.get_variable(name='weights',
shape=[kernel_size, kernel_size, input_size, output_size],
initializer=tf.random_normal_initializer(mean=0, stddev=0.01),
dtype=tf.float32)
if wd is not None:
# wd 0.004
# tf.nn.l2_loss(var)=sum(t**2)/2
weight_decay = tf.multiply(tf.nn.l2_loss(conv_weights), wd, name='weight_loss')
tf.add_to_collection('losses', weight_decay)
conv_biases = tf.get_variable(name='biases',
shape=[output_size],
initializer=tf.constant_initializer(init_bias),
dtype=tf.float32)
conv_layer = tf.nn.conv2d(input, conv_weights, [1, stride, stride, 1], padding=padding, name=name) # 卷積操作
conv_layer = tf.nn.bias_add(conv_layer, conv_biases) # 加上偏置項
conv_layer = tf.nn.relu(conv_layer) # relu激活函數
return conv_layer
conv函數
def fc(input, output_size, init_bias=0.0, activeation_func=True, wd=None):
input_shape = input.get_shape().as_list()
# 創建 全連接權重 變量
fc_weights = tf.get_variable(name="weights",
shape=[input_shape[-1], output_size],
initializer=tf.random_normal_initializer(mean=0.0, stddev=0.01),
dtype=tf.float32)
if wd is not None:
# wd 0.004
# tf.nn.l2_loss(var)=sum(t**2)/2
weight_decay = tf.multiply(tf.nn.l2_loss(fc_weights), wd, name='weight_loss')
tf.add_to_collection('losses', weight_decay)
# 創建 全連接偏置 變量
fc_biases = tf.get_variable(name="biases",
shape=[output_size],
initializer=tf.constant_initializer(init_bias),
dtype=tf.float32)
fc_layer = tf.matmul(input, fc_weights) # 全連接計算
fc_layer = tf.nn.bias_add(fc_layer, fc_biases) # 加上偏置項
if activeation_func:
fc_layer = tf.nn.relu(fc_layer) # rele激活函數
return fc_layer
fc函數
def LRN(input, depth_radius=2, alpha=0.0001, beta=0.75, bias=1.0):
"""Local Response Normalization 局部響應歸一化"""
return tf.nn.local_response_normalization(input, depth_radius=depth_radius, alpha=alpha,
beta=beta, bias=bias)
LRN函數
然後利用我們搭建的神經網絡單元,搭建Alex神經網絡模型
def alexNet(inputs, class_num, keep_prob=0.5):
# 第一層卷積層 conv1
with tf.variable_scope("conv1"):
conv1 = conv(input=inputs, kernel_size=7, output_size=96, stride=3, init_bias=0.0, name="conv1", padding="SAME")
conv1 = LRN(conv1)
conv1 = tf.nn.max_pool(conv1, ksize=[1, 3, 3, 1], strides=[1, 2, 2, 1], padding='VALID', name="pool1")
# 第二層卷積層 conv2
with tf.variable_scope("conv2"):
conv2 = conv(input=conv1, kernel_size=7, output_size=96, stride=3, init_bias=1.0, name="conv2", padding="SAME")
conv2 = LRN(conv2)
conv2 = tf.nn.max_pool(conv2, ksize=[1, 3, 3, 1], strides=[1, 2, 2, 1], padding='VALID', name="pool2")
# 第三層卷積層 conv3
with tf.variable_scope("conv3"):
conv3 = conv(input=conv2, kernel_size=7, output_size=96, stride=3, init_bias=0.0, name="conv3", padding="SAME")
# 第四層卷積層 conv4
with tf.variable_scope("conv4"):
conv4 = conv(input=conv3, kernel_size=7, output_size=96, stride=3, init_bias=1.0, name="conv4", padding="SAME")
# 第五層卷積層 conv5
with tf.variable_scope("conv5"):
conv5 = conv(input=conv4, kernel_size=3, output_size=256, stride=1, init_bias=1.0, name="conv5")
conv5 = tf.nn.max_pool(conv5, ksize=[1, 3, 3, 1], strides=[1, 2, 2, 1], padding='VALID', name="pool5")
conv5_shape = conv5.shape # 後面做全連接,所以要把shape改成2維
# shape=[batch, dim]
flatten = tf.reshape(conv5, [-1, conv5_shape[1] * conv5_shape[2] * conv5_shape[3]])
# 第一層全連接層 fc1
with tf.variable_scope("fc1"):
fc1 = fc(input=flatten, output_size=4096, init_bias=1.0, activeation_func=tf.nn.relu, wd=None)
fc1 = tf.nn.dropout(fc1, keep_prob=keep_prob, name="dropout1")
# 第一層全連接層 fc2
with tf.variable_scope("fc2"):
fc2 = fc(input=fc1, output_size=4096, init_bias=1.0, activeation_func=tf.nn.relu, wd=None)
fc2 = tf.nn.dropout(fc2, keep_prob=keep_prob, name="dropout1")
# 第一層全連接層 fc3
with tf.variable_scope("fc3"):
logit = fc(input=fc2, output_size=class_num, init_bias=1.0, activeation_func=False, wd=None)
return logit # 模型輸出
VGG模型
論文:2014_VGG_Very Deep Convolutional Networks for Large-Scale Image Recognition
VGG有兩個比較有名的網絡:VGG16、VGG19,我在這裏搭建VGG16,有興趣的朋友可以按照上面的模型結構自己用TensorFlow搭建VGG19模型
下面我們定義一個VGG16模型,和前面一樣,我們先定義需要用到的神經網絡單元,相同的代碼盡量封裝成函數的形式以節省代碼量和簡潔代碼
因為模型中同一個變量域中包含多個卷積操作,因此在卷積函數中套一層變量域
def conv(inputs, scope_name, kernel_size, output_size, stride, init_bias=0.0, padding="SAME", wd=None):
input_size = int(inputs.get_shape()[-1])
with tf.variable_scope(scope_name):
conv_weights = tf.get_variable(name='weights',
shape=[kernel_size, kernel_size, input_size, output_size],
dtype=tf.float32,
initializer=tf.truncated_normal_initializer(mean=0.0, stddev=1e-1))
if wd is not None:
# tf.nn.l2_loss(var)=sum(t**2)/2
weight_decay = tf.multiply(tf.nn.l2_loss(conv_weights), wd, name='weight_loss')
tf.add_to_collection('losses', weight_decay)
conv_biases = tf.get_variable(name='biases',
shape=[output_size],
dtype=tf.float32,
initializer=tf.constant_initializer(init_bias))
conv_layer = tf.nn.conv2d(inputs, conv_weights, [1, stride, stride, 1], padding=padding, name=scope_name)
conv_layer = tf.nn.bias_add(conv_layer, conv_biases)
conv_layer = tf.nn.relu(conv_layer)
return conv_layer
conv函數
def fc(inputs, scope_name, output_size, init_bias=0.0, activeation_func=True, wd=None):
input_shape = inputs.get_shape().as_list()
with tf.variable_scope(scope_name):
# 創建 全連接權重 變量
fc_weights = tf.get_variable(name="weights",
shape=[input_shape[-1], output_size],
dtype=tf.float32,
initializer=tf.truncated_normal_initializer(mean=0.0, stddev=1e-1))
if wd is not None:
# wd 0.004
# tf.nn.l2_loss(var)=sum(t**2)/2
weight_decay = tf.multiply(tf.nn.l2_loss(fc_weights), wd, name='weight_loss')
tf.add_to_collection('losses', weight_decay)
# 創建 全連接偏置 變量
fc_biases = tf.get_variable(name="biases",
shape=[output_size],
dtype=tf.float32,
initializer=tf.constant_initializer(init_bias),
trainable=True)
fc_layer = tf.matmul(inputs, fc_weights) # 全連接計算
fc_layer = tf.nn.bias_add(fc_layer, fc_biases) # 加上偏置項
if activeation_func:
fc_layer = tf.nn.relu(fc_layer) # rele激活函數
return fc_layer
fc函數
然後利用我們搭建的神經網絡單元,搭建VGG16神經網絡模型
def VGG16Net(inputs, class_num):
with tf.variable_scope("conv1"):
# conv1_1 [conv3_64]
conv1_1 = conv(inputs=inputs, scope_name="conv1_1", kernel_size=3, output_size=64, stride=1,
init_bias=0.0, padding="SAME")
# conv1_2 [conv3_64]
conv1_2 = conv(inputs=conv1_1, scope_name="conv1_2", kernel_size=3, output_size=64, stride=1,
init_bias=0.0, padding="SAME")
pool1 = tf.nn.max_pool(conv1_2, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME', name='pool1')
with tf.variable_scope("conv2"):
# conv2_1
conv2_1 = conv(inputs=pool1, scope_name="conv2_1", kernel_size=3, output_size=128, stride=1,
init_bias=0.0, padding="SAME")
# conv2_2
conv2_2 = conv(inputs=conv2_1, scope_name="conv2_2", kernel_size=3, output_size=128, stride=1,
init_bias=0.0, padding="SAME")
pool2 = tf.nn.max_pool(conv2_2, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME', name='pool2')
with tf.variable_scope("conv3"):
# conv3_1
conv3_1 = conv(inputs=pool2, scope_name="conv3_1", kernel_size=3, output_size=256, stride=1,
init_bias=0.0, padding="SAME")
# conv3_2
conv3_2 = conv(inputs=conv3_1, scope_name="conv3_2", kernel_size=3, output_size=256, stride=1,
init_bias=0.0, padding="SAME")
# conv3_3
conv3_3 = conv(inputs=conv3_2, scope_name="conv3_3", kernel_size=3, output_size=256, stride=1,
init_bias=0.0, padding="SAME")
pool3 = tf.nn.max_pool(conv3_3, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME', name='pool3')
with tf.variable_scope("conv4"):
# conv4_1
conv4_1 = conv(inputs=pool3, scope_name="conv4_1", kernel_size=3, output_size=512, stride=1,
init_bias=0.0, padding="SAME")
# conv4_2
conv4_2 = conv(inputs=conv4_1, scope_name="conv4_2", kernel_size=3, output_size=512, stride=1,
init_bias=0.0, padding="SAME")
# conv4_3
conv4_3 = conv(inputs=conv4_2, scope_name="conv4_3", kernel_size=3, output_size=512, stride=1,
init_bias=0.0, padding="SAME")
pool4 = tf.nn.max_pool(conv4_3, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME', name='pool4')
with tf.variable_scope("conv5"):
# conv5_1
conv5_1 = conv(inputs=pool4, scope_name="conv4_1", kernel_size=3, output_size=512, stride=1,
init_bias=0.0, padding="SAME")
# conv5_2
conv5_2 = conv(inputs=conv5_1, scope_name="conv4_2", kernel_size=3, output_size=512, stride=1,
init_bias=0.0, padding="SAME")
# conv5_3
conv5_3 = conv(inputs=conv5_2, scope_name="conv4_3", kernel_size=3, output_size=512, stride=1,
init_bias=0.0, padding="SAME")
pool5 = tf.nn.max_pool(conv5_3, ksize=[1, 2, 2, 1], strides=[1, 2, 2, 1], padding='SAME', name='pool4')
input_shape = pool5.get_shape().as_list() # 後面做全連接,所以要把shape改成2維
# shape=[batch, dim]
flatten = tf.reshape(pool5, [-1, input_shape[1] * input_shape[2] * input_shape[3]])
fc1 = fc(inputs=flatten, scope_name="fc1", output_size=4096, init_bias=1.0, activeation_func=True)
fc2 = fc(inputs=fc1, scope_name="fc2", output_size=4096, init_bias=1.0, activeation_func=True)
fc3 = fc(inputs=fc2, scope_name="fc3", output_size=class_num, init_bias=1.0, activeation_func=True)
return fc3
上圖中有一個softmax層,我們也可以定義出來
class_num = 1000
# placeholder 定義
inputs = tf.placeholder(dtype="float", shape=[None, 28, 28, 3], name='inputs')
labels = tf.placeholder(dtype="float", shape=[None, class_num], name='labels')
learning_rate = tf.placeholder("float", None, name='learning_rate')
logits = VGG16Net(inputs)
probs = tf.nn.softmax(logits)
ResNet模型
論文:
- 2016_ResNet_Deep Residual Learning for Image Recognition
- 2016_ResNet_Identity Mappings in Deep Residual Networks
ResNet的網絡結構如下圖所示
我們先定義需要用到的神經網絡單元
def batch_normalization(inputs, output_size):
mean, variance = tf.nn.moments(inputs, axes=[0, 1, 2]) # 計算均值和方差
beta = tf.get_variable('beta', output_size, tf.float32, initializer=tf.zeros_initializer)
gamma = tf.get_variable('gamma', output_size, tf.float32, initializer=tf.ones_initializer)
bn_layer = tf.nn.batch_normalization(inputs, mean, variance, beta, gamma, 0.001)
return bn_layer
batch_normalization函數
def conv(input, kernel_size, output_size, stride, padding="SAME", wd=None):
input_size = input.shape[-1]
conv_weights = tf.get_variable(name='weights',
shape=[kernel_size, kernel_size, input_size, output_size],
dtype=tf.float32,
initializer=tf.truncated_normal_initializer(mean=0.0, stddev=0.1),
regularizer=tf.contrib.layers.l2_regularizer(0.00004)) # 正則損失衰減率0.000004
conv_layer = tf.nn.conv2d(input, conv_weights, [1, stride, stride, 1], padding=padding) # 卷積操作
batch_norm = batch_normalization(conv_layer, output_size)
conv_output = tf.nn.relu(batch_norm) # relu激活函數
return conv_output
conv函數
def fc(input, output_size, activeation_func=True):
input_shape = input.shape[-1]
# 創建 全連接權重 變量
fc_weights = tf.get_variable(name="weights",
shape=[input_shape, output_size],
initializer=tf.truncated_normal_initializer(stddev=0.01),
dtype=tf.float32,
regularizer=tf.contrib.layers.l2_regularizer(0.01))
# 創建 全連接偏置 變量
fc_biases = tf.get_variable(name="biases",
shape=[output_size],
initializer=tf.zeros_initializer,
dtype=tf.float32)
fc_layer = tf.matmul(input, fc_weights) # 全連接計算
fc_layer = tf.nn.bias_add(fc_layer, fc_biases) # 加上偏置項
if activeation_func:
fc_layer = tf.nn.relu(fc_layer) # rele激活函數
return fc_layer
fc函數
def block(input, n, output_size, change_first_stride, bottleneck):
if n == 0 and change_first_stride:
stride = 2
else:
stride = 1
if bottleneck:
with tf.variable_scope('a'):
conv_a = conv(input=input, kernel_size=1, output_size=output_size, stride=stride, padding="SAME")
conv_a = batch_normalization(conv_a, output_size)
conv_a = tf.nn.relu(conv_a)
with tf.variable_scope('b'):
conv_b = conv(input=conv_a, kernel_size=3, output_size=output_size, stride=1, padding="SAME")
conv_b = batch_normalization(conv_b, output_size)
conv_b = tf.nn.relu(conv_b)
with tf.variable_scope('c'):
conv_c = conv(input=conv_b, kernel_size=1, output_size=output_size * 4, stride=1, padding="SAME")
output = batch_normalization(conv_c, output_size * 4)
else:
with tf.variable_scope('A'):
conv_A = conv(input=input, kernel_size=3, output_size=output_size, stride=stride, padding="SAME")
conv_A = batch_normalization(conv_A, output_size)
conv_A = tf.nn.relu(conv_A)
with tf.variable_scope('B'):
conv_B = conv(input=conv_A, kernel_size=3, output_size=output_size, stride=1, padding="SAME")
output = batch_normalization(conv_B, output_size)
if input.shape == output.shape:
with tf.variable_scope('shortcut'):
shortcut = input # shortcut
else:
with tf.variable_scope('shortcut'):
shortcut = conv(input=input, kernel_size=1, output_size=output_size * 4, stride=1, padding="SAME")
shortcut = batch_normalization(shortcut, output_size * 4)
return tf.nn.relu(output + shortcut)
block函數
然後我們定義神經網絡框架
def inference(inputs, class_num, num_blocks=[3, 4, 6, 3], bottleneck=True):
# data[1, 224, 224, 3]
# 我們嘗試搭建50層ResNet
with tf.variable_scope('conv1'):
conv1 = conv(input=inputs, kernel_size=7, output_size=64, stride=2, padding="SAME")
conv1 = batch_normalization(inputs=conv1, output_size=64)
conv1 = tf.nn.relu(conv1)
with tf.variable_scope('conv2_x'):
conv_output = tf.nn.max_pool(conv1, ksize=[1, 3, 3, 1], strides=[1, 2, 2, 1], padding='SAME')
for n in range(num_blocks[0]):
with tf.variable_scope('block%d' % (n + 1)):
conv_output = block(conv_output, n, output_size=64, change_first_stride=False, bottleneck=bottleneck)
with tf.variable_scope('conv3_x'):
for n in range(num_blocks[1]):
with tf.variable_scope('block%d' % (n + 1)):
conv_output = block(conv_output, n, output_size=128, change_first_stride=True, bottleneck=bottleneck)
with tf.variable_scope('conv4_x'):
for n in range(num_blocks[2]):
with tf.variable_scope('block%d' % (n + 1)):
conv_output = block(conv_output, n, output_size=256, change_first_stride=True, bottleneck=bottleneck)
with tf.variable_scope('conv5_x'):
for n in range(num_blocks[3]):
with tf.variable_scope('block%d' % (n + 1)):
conv_output = block(conv_output, n, output_size=512, change_first_stride=True, bottleneck=bottleneck)
output = tf.reduce_mean(conv_output, reduction_indices=[1, 2], name="avg_pool")
with tf.variable_scope('fc'):
output = fc(output, class_num, activeation_func=False)
return output
Google Inception Net模型
Inception Net模型 以後再更新吧,如果這篇文章對大家有用,歡迎大家催促我。
RNN模型
Tensorflow中的CNN變數很少,而RNN卻豐富多彩,不僅在RNN Cell上有很多種、在實現上也有很多種,在用法上更是花樣百出。
五個基本的RNN Cell:RNNCell、BasicRNNCell、LSTMCell、BasicLSTMCell、GRUCell
RNN Cell的封裝和變形:MultiRNNCell(多層RNN)、DropoutWrapper、ResidualWrapper、DeviceWrapper
四種架構 (static+dynamic)*(單向+雙向)=4:static_rnn(靜態RNN)、dynamic_rnn(動態RNN)、static_bidirectional_rnn(靜態雙向RNN)、bidirectional_dynamic_rnn(動態雙向RNN)
五種手法 (one+many)*(one+many) +1=5:
- one to one(1 vs 1):輸入一個,輸出一個。其實和全連接神經網絡並沒有什麼區別,這一類別算不得是 RNN。
- one to many(1 vs N):輸入一個,輸出多個。圖像標註,輸入一個圖片,得到對圖片的語言描述
- many to one(N vs 1):輸入多個,輸出一個。序列分類,把序列壓縮成一個向量
- many to many(N vs N):輸入多個,輸出多個。兩者長度可以不一樣。翻譯任務
- many to many(N vs N):輸入多個,輸出多個。兩者長度一樣。char RNN
我們先定義需要用到的神經網絡單元
全連接層
def fc(input, output_size, activeation_func=tf.nn.relu):
input_shape = input.shape[-1]
# 創建 全連接權重 變量
fc_weights = tf.get_variable(name="weights",
shape=[input_shape, output_size],
initializer=tf.truncated_normal_initializer(stddev=0.01),
dtype=tf.float32,
regularizer=tf.contrib.layers.l2_regularizer(0.01))
# 創建 全連接偏置 變量
fc_biases = tf.get_variable(name="biases",
shape=[output_size],
initializer=tf.zeros_initializer,
dtype=tf.float32)
fc_layer = tf.matmul(input, fc_weights) # 全連接計算
fc_layer = tf.nn.bias_add(fc_layer, fc_biases) # 加上偏置項
if activeation_func:
fc_layer = activeation_func(fc_layer) # rele激活函數
return fc_layer
View Code
單層 靜態/動態 LSTM/GRU
#######################################
# 單層 靜態/動態 LSTM/GRU #
#######################################
# 單層靜態LSTM
def single_layer_static_lstm(input_x, time_steps, hidden_size):
"""
:param input_x: 輸入張量 形狀為[batch_size, n_steps, input_size]
:param n_steps: 時序總數
:param n_hidden: LSTM單元輸出的節點個數 即隱藏層節點數
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x1 = tf.unstack(input_x, num=time_steps, axis=1)
lstm_cell = tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size) # 創建LSTM_cell
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
output, states = tf.nn.static_rnn(cell=lstm_cell, inputs=input_x1, dtype=tf.float32) # 通過cell類構建RNN
return output, states
# 單層靜態gru
def single_layer_static_gru(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size, n_steps, input_size]
:param n_steps: 時序總數
:param n_hidden: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回靜態單層GRU單元的輸出,以及cell狀態
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x = tf.unstack(input, num=time_steps, axis=1)
gru_cell = tf.nn.rnn_cell.GRUCell(num_units=hidden_size) # 創建GRU_cell
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
output, states = tf.nn.static_rnn(cell=gru_cell, inputs=input_x, dtype=tf.float32) # 通過cell類構建RNN
return output, states
# 單層動態LSTM
def single_layer_dynamic_lstm(input, time_steps, hidden_size):
"""
:param input_x: 輸入張量 形狀為[batch_size, time_steps, input_size]
:param time_steps: 時序總數
:param hidden_size: LSTM單元輸出的節點個數 即隱藏層節點數
:return: 返回動態單層LSTM單元的輸出,以及cell狀態
"""
lstm_cell = tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size) # 創建LSTM_cell
# 動態rnn函數傳入的是一個三維張量,[batch_size,time_steps, input_size] 輸出也是這種形狀
output, states = tf.nn.dynamic_rnn(cell=lstm_cell, inputs=input, dtype=tf.float32) # 通過cell類構建RNN
output = tf.transpose(output, [1, 0, 2]) # 注意這裏輸出需要轉置 轉換為時序優先的
return output, states
# 單層動態gru
def single_layer_dynamic_gru(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size, time_steps, input_size]
:param time_steps: 時序總數
:param hidden_size: GRU單元輸出的節點個數 即隱藏層節點數
:return: 返回動態單層GRU單元的輸出,以及cell狀態
"""
gru_cell = tf.nn.rnn_cell.GRUCell(num_units=hidden_size) # 創建GRU_cell
# 動態rnn函數傳入的是一個三維張量,[batch_size,n_steps,input_size] 輸出也是這種形狀
output, states = tf.nn.dynamic_rnn(cell=gru_cell, inputs=input, dtype=tf.float32) # 通過cell類構建RNN
output = tf.transpose(output, [1, 0, 2]) # 注意這裏輸出需要轉置 轉換為時序優先的
return output, states
View Code
多層 靜態/動態 LSTM/GRU
#######################################
# 多層 靜態/動態 LSTM/GRU #
#######################################
# 多層靜態LSTM網絡
def multi_layer_static_lstm(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,time_steps,input_size]
:param time_steps: 時序總數
:param n_hidden: LSTM單元輸出的節點個數 即隱藏層節點數
:return: 返回靜態多層LSTM單元的輸出,以及cell狀態
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x1 = tf.unstack(input, num=time_steps, axis=1)
# 多層RNN的實現 例如cells=[cell1,cell2,cell3],則表示一共有三層
mcell = tf.nn.rnn_cell.MultiRNNCell(
[tf.nn.rnn_cell.LSTMCell(num_units=hidden_size) for _ in range(3)])
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
output, states = tf.nn.static_rnn(cell=mcell, inputs=input_x1, dtype=tf.float32)
return output, states
# 多層靜態GRU
def multi_layer_static_gru(input, time_steps, hidden_size):
"""
:param input_x: 輸入張量 形狀為[batch_size,n_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回靜態多層GRU單元的輸出,以及cell狀態
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x = tf.unstack(input, num=time_steps, axis=1)
# 多層RNN的實現 例如cells=[cell1,cell2,cell3],則表示一共有三層
mcell = tf.nn.rnn_cell.MultiRNNCell(
[tf.nn.rnn_cell.GRUCell(num_units=hidden_size) for _ in range(3)])
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
output, states = tf.nn.static_rnn(cell=mcell, inputs=input_x, dtype=tf.float32)
return output, states
# 多層靜態GRU和LSTM 混合
def multi_layer_static_mix(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,n_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回靜態多層GRU和LSTM混合單元的輸出,以及cell狀態
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x = tf.unstack(input, num=time_steps, axis=1)
# 可以看做2個隱藏層
lstm_cell = tf.nn.rnn_cell.LSTMCell(num_units=hidden_size)
gru_cell = tf.nn.rnn_cell.GRUCell(num_units=hidden_size * 2)
# 多層RNN的實現 例如cells=[cell1,cell2],則表示一共有兩層,數據經過cell1后還要經過cells
mcell = tf.nn.rnn_cell.MultiRNNCell(cells=[lstm_cell, gru_cell])
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
output, states = tf.nn.static_rnn(cell=mcell, inputs=input_x, dtype=tf.float32)
return output, states
# 多層動態LSTM
def multi_layer_dynamic_lstm(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,n_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: LSTM單元輸出的節點個數 即隱藏層節點數
:return: 返回動態多層LSTM單元的輸出,以及cell狀態
"""
# 多層RNN的實現 例如cells=[cell1,cell2],則表示一共有兩層,數據經過cell1后還要經過cells
mcell = tf.nn.rnn_cell.MultiRNNCell(
[tf.nn.rnn_cell.LSTMCell(num_units=hidden_size) for _ in range(3)])
# 動態rnn函數傳入的是一個三維張量,[batch_size,n_steps,input_size] 輸出也是這種形狀
output, states = tf.nn.dynamic_rnn(cell=mcell, inputs=input, dtype=tf.float32)
# 注意這裏輸出需要轉置 轉換為時序優先的
output = tf.transpose(output, [1, 0, 2])
return output, states
# 多層動態GRU
def multi_layer_dynamic_gru(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,n_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回動態多層GRU單元的輸出,以及cell狀態
"""
# 多層RNN的實現 例如cells=[cell1,cell2],則表示一共有兩層,數據經過cell1后還要經過cells
mcell = tf.nn.rnn_cell.MultiRNNCell(
[tf.nn.rnn_cell.GRUCell(num_units=hidden_size) for _ in range(3)])
# 動態rnn函數傳入的是一個三維張量,[batch_size,n_steps,input_size] 輸出也是這種形狀
output, states = tf.nn.dynamic_rnn(cell=mcell, inputs=input, dtype=tf.float32)
# 注意這裏輸出需要轉置 轉換為時序優先的
output = tf.transpose(output, [1, 0, 2])
return output, states
# 多層動態GRU和LSTM 混合
def multi_layer_dynamic_mix(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,n_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回動態多層GRU和LSTM混合單元的輸出,以及cell狀態
"""
# 可以看做2個隱藏層
gru_cell = tf.nn.rnn_cell.GRUCell(num_units=hidden_size * 2)
lstm_cell = tf.nn.rnn_cell.LSTMCell(num_units=hidden_size)
# 多層RNN的實現 例如cells=[cell1,cell2],則表示一共有兩層,數據經過cell1后還要經過cells
mcell = tf.nn.rnn_cell.MultiRNNCell(cells=[lstm_cell, gru_cell])
# 動態rnn函數傳入的是一個三維張量,[batch_size,n_steps,input_size] 輸出也是這種形狀
output, states = tf.nn.dynamic_rnn(cell=mcell, inputs=input, dtype=tf.float32)
# 注意這裏輸出需要轉置 轉換為時序優先的
output = tf.transpose(output, [1, 0, 2])
return output, states
View Code
單層/多層 雙向 靜態/動態 LSTM/GRU
#######################################
# 單層/多層 雙向 靜態/動態 LSTM/GRU #
#######################################
# 單層靜態雙向LSTM
def single_layer_static_bi_lstm(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,time_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: LSTM單元輸出的節點個數 即隱藏層節點數
:return: 返回單層靜態雙向LSTM單元的輸出,以及cell狀態
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x = tf.unstack(input, num=time_steps, axis=1)
lstm_fw_cell = tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size) # 正向
lstm_bw_cell = tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size) # 反向
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
# 這裏的輸出output是一個list 每一個元素都是前向輸出,後向輸出的合併
output, fw_state, bw_state = tf.nn.static_bidirectional_rnn(cell_fw=lstm_fw_cell,
cell_bw=lstm_bw_cell,
inputs=input_x,
dtype=tf.float32)
print(type(output)) # <class 'list'>
print(len(output)) # 28
print(output[0].shape) # (?, 256)
return output, fw_state, bw_state
# 單層動態雙向LSTM
def single_layer_dynamic_bi_lstm(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,time_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回單層動態雙向LSTM單元的輸出,以及cell狀態
"""
lstm_fw_cell = tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size) # 正向
lstm_bw_cell = tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size) # 反向
# 動態rnn函數傳入的是一個三維張量,[batch_size,time_steps,input_size] 輸出是一個元組 每一個元素也是這種形狀
output, state = tf.nn.bidirectional_dynamic_rnn(cell_fw=lstm_fw_cell,
cell_bw=lstm_bw_cell,
inputs=input,
dtype=tf.float32)
print(type(output)) # <class 'tuple'>
print(len(output)) # 2
print(output[0].shape) # (?, 28, 128)
print(output[1].shape) # (?, 28, 128)
output = tf.concat(output, axis=2) # 按axis=2合併 (?,28,128) (?,28,128)按最後一維合併(?,28,256)
output = tf.transpose(output, [1, 0, 2]) # 注意這裏輸出需要轉置 轉換為時序優先的
return output, state
# 多層靜態雙向LSTM
def multi_layer_static_bi_lstm(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,time_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: LSTM單元輸出的節點個數 即隱藏層節點數
:return: 返回多層靜態雙向LSTM單元的輸出,以及cell狀態
"""
# 把輸入input_x按列拆分,並返回一個有n_steps個張量組成的list
# 如batch_sizex28x28的輸入拆成[(batch_size,28),((batch_size,28))....]
# 如果是調用的是靜態rnn函數,需要這一步處理 即相當於把序列作為第一維度
input_x = tf.unstack(input, num=time_steps, axis=1)
stacked_fw_rnn = []
stacked_bw_rnn = []
for i in range(3):
stacked_fw_rnn.append(tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size)) # 正向
stacked_bw_rnn.append(tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size)) # 反向
# 靜態rnn函數傳入的是一個張量list 每一個元素都是一個(batch_size,input_size)大小的張量
# 這裏的輸出output是一個list 每一個元素都是前向輸出,後向輸出的合併
output, fw_state, bw_state = tf.contrib.rnn.stack_bidirectional_rnn(stacked_fw_rnn,
stacked_bw_rnn,
inputs=input_x,
dtype=tf.float32)
print(type(output)) # <class 'list'>
print(len(output)) # 28
print(output[0].shape) # (?, 256)
return output, fw_state, bw_state
# 多層動態雙向LSTM
def multi_layer_dynamic_bi_lstm(input, time_steps, hidden_size):
"""
:param input: 輸入張量 形狀為[batch_size,n_steps,input_size]
:param time_steps: 時序總數
:param hidden_size: gru單元輸出的節點個數 即隱藏層節點數
:return: 返回多層動態雙向LSTM單元的輸出,以及cell狀態
"""
stacked_fw_rnn = []
stacked_bw_rnn = []
for i in range(3):
stacked_fw_rnn.append(tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size)) # 正向
stacked_bw_rnn.append(tf.nn.rnn_cell.BasicLSTMCell(num_units=hidden_size)) # 反向
# 動態rnn函數傳入的是一個三維張量,[batch_size,n_steps,input_size] 輸出也是這種形狀,
# input_size變成了正向和反向合併之後的 即input_size*2
output, fw_state, bw_state = tf.contrib.rnn.stack_bidirectional_dynamic_rnn(stacked_fw_rnn,
stacked_bw_rnn,
inputs=input,
dtype=tf.float32)
print(type(output)) # <class 'tensorflow.python.framework.ops.Tensor'>
print(output.shape) # (?, 28, 256)
output = tf.transpose(output, [1, 0, 2]) # 注意這裏輸出需要轉置 轉換為時序優先的
return output, fw_state, bw_state
View Code
然後我們定義神經網絡框架
※台中搬家遵守搬運三大原則,讓您的家具不再被破壞!
台中搬家公司推薦超過30年經驗,首選台中大展搬家
def RNN_inference(inputs, class_num, time_steps, hidden_size):
"""
:param inputs: [batch_size, n_steps, input_size]
:param class_num: 類別數
:param time_steps: 時序總數
:param n_hidden: LSTM單元輸出的節點個數 即隱藏層節點數
"""
#######################################
# 單層 靜態/動態 LSTM/GRU #
#######################################
# outputs, states = single_layer_static_lstm(inputs, time_steps, hidden_size) # 單層靜態LSTM
# outputs, states = single_layer_static_gru(inputs, time_steps, hidden_size) # 單層靜態gru
# outputs, states = single_layer_dynamic_lstm(inputs, time_steps, hidden_size) # 單層動態LSTM
# outputs, states = single_layer_dynamic_gru(inputs, time_steps, hidden_size) # 單層動態gru
#######################################
# 多層 靜態/動態 LSTM/GRU #
#######################################
# outputs, states = multi_layer_static_lstm(inputs, time_steps, hidden_size) # 多層靜態LSTM網絡
# outputs, states = multi_layer_static_gru(inputs, time_steps, hidden_size) # 多層靜態GRU
# outputs, states = multi_layer_static_mix(inputs, time_steps, hidden_size) # 多層靜態GRU和LSTM 混合
# outputs, states = multi_layer_dynamic_lstm(inputs, time_steps, hidden_size) # 多層動態LSTM
# outputs, states = multi_layer_dynamic_gru(inputs, time_steps, hidden_size) # 多層動態GRU
# outputs, states = multi_layer_dynamic_mix(inputs, time_steps, hidden_size) # 多層動態GRU和LSTM 混合
#######################################
# 單層/多層 雙向 靜態/動態 LSTM/GRU #
#######################################
# outputs, fw_state, bw_state = single_layer_static_bi_lstm(inputs, time_steps, hidden_size) # 單層靜態雙向LSTM
# outputs, state = single_layer_dynamic_bi_lstm(inputs, time_steps, hidden_size) # 單層動態雙向LSTM
# outputs, fw_state, bw_state = multi_layer_static_bi_lstm(inputs, time_steps, hidden_size) # 多層靜態雙向LSTM
outputs, fw_state, bw_state = multi_layer_dynamic_bi_lstm(inputs, time_steps, hidden_size) # 多層動態雙向LSTM
# output靜態是 time_step=28個(batch=128, output=128)組成的列表
# output動態是 (time_step=28, batch=128, output=128)
print('hidden:', outputs[-1].shape) # 最後一個時序的shape(128,128)
# 取LSTM最後一個時序的輸出,然後經過全連接網絡得到輸出值
fc_output = fc(input=outputs[-1], output_size=class_num, activeation_func=tf.nn.relu)
return fc_output
設置全局變量和超參數
在模型訓練之前我們首先會定義一些超參數:batch_size、batch_nums、class_num、epochs、learning_rate
batch_size = FLAGS.batch_size
batch_nums = mnist.train.images.shape[0] // batch_size # 一個epoch中應該包含多少batch數據
class_num = FLAGS.class_num
epochs = FLAGS.epochs
learning_rate = FLAGS.learning_rate
保存檢查點的地址
############ 保存檢查點的地址 ############
checkpoints_dir = FLAGS.checkpoints_dir # checkpoints
# 如果檢查點不存在,則創建
if not os.path.exists(checkpoints_dir):
os.makedirs(FLAGS.checkpoints_dir)
創建圖
這一步可以不設置,因為tensorflow有一個默認圖,我們定義的操作都是在默認圖上的,當然我們也可以定義自己的,方便管理。
######################################################
# 創建圖 #
######################################################
graph = tf.Graph() # 自定義圖
# 在自己的圖中定義數據和操作
with graph.as_default():
佔位符
一般我們會把input和label做成placeholder,方便我們使用把不同的batch數據傳入網絡,一些其他的超參數也可以做成placeholder,比如learning_rate、dorpout_keep_prob。一般在搭建模型的時候把placeholder的變量傳入模型,在訓練模型sess.run(train_op, feed_dict)的時候通過參數feed_dict={input:真實數據,label:真實標籤} 把真實的數據傳入神經網絡。
inputs = tf.placeholder(dtype="float", shape=[None, 28, 28, 1], name='inputs')
labels = tf.placeholder(dtype="float", shape=[None, class_num], name='labels')
# 看個人喜歡,有的人在初始化定義中就定義了learning_rate,有的人喜歡通過feed傳learning_rate
learning_rate = tf.placeholder("float", None, name='learning_rate')
# 如果網絡結構有dropout層,需要定義keep_probn,如果沒有則不需要
# 訓練的時候需要,測試的時候需要設置成1
keep_prob = tf.placeholder(dtype="float", name='keep_prob')
搭建模型
傳進入的都是placeholder數據,不是我們之前整理好的batch數據。
############ 搭建模型 ############
logits = alexNet(inputs, class_num, keep_prob=keep_prob) # 使用placeholder搭建模型
構建損失
分類任務一般輸出的是每個類別的概率向量,因此模型輸出最後都要經過softmax轉換成概率。一般經過softmax的輸出損失函數都是交叉熵損失函數,tensorflow有將以上兩步合在一起的現成函數 tf.nn.softmax_cross_entropy_with_logits
############ 損失函數 ############
loss = tf.reduce_mean(tf.nn.softmax_cross_entropy_with_logits(labels=labels, logits=logits))
tf.add_to_collection('losses', loss)
total_loss = tf.add_n(tf.get_collection("loss")) # total_loss=模型損失+權重正則化損失
自定義損失
以後更新,歡迎大家催我。
模型精度
在測試數據集上的精度
############ 模型精度 ############
predict = tf.argmax(logits, 1) # 模型預測結果
accuracy = tf.reduce_mean(tf.cast(tf.equal(predict, tf.argmax(labels, 1)), tf.float32))
自定義度量
以後更新,歡迎大家催我。
優化器
創建優化器,更新網絡參數,最小化loss
優化器的種類有很多種,但是用法都差不多,常用的優化器有:
下面以Adam優化器為例
############ 優化器 ############
variable_to_train = tf.get_collection(tf.GraphKeys.TRAINABLE_VARIABLES) # 可訓練變量列表
global_step = tf.Variable(0, trainable=False) # 訓練step
# 設置學習率衰減
learning_rate = tf.train.exponential_decay(learning_rate=learning_rate, # 初始學習率
global_step=global_step,
decay_steps=batch_nums, # 多少步衰減一次
decay_rate=0.1, # 衰減率
staircase=True) # 以階梯的形式衰減
# 創建Adam優化器,更新模型參數,最小化損失函數
train_op = tf.train.AdamOptimizer(learning_rate).minimize(loss=total_loss, # 損失函數
global_step=global_step,
var_list=variable_to_train) # 通過訓練需要更新的參數列表
講解:
- variable_to_train:上面的代碼定義了可訓練變量,我只是把列出了模型默認的可訓練變量,這一個步是tensorflow默認的,如果不設置也沒有關係。我寫出來的原因是,有的大牛會這麼寫,對不同的可訓練變量分別進行不同的優化,希望大家看到我的代碼,下次看到別人的不會覺得陌生。
- global_step:大多數人會用step=0,然後在訓練的時候step+=1的方式更新step,但是本文介紹的是另一種方式,以tf.Variable的方式定義step,在模型訓練的時候傳入sess.run,global_step會自動+1更新
- learning_rate:本文還設置了學習率衰減,大家也可以不設置,以固定的學習率訓練模型,但是對於大型項目,還是推薦設置。
移動平均值更新參數
採用移動平均值的方式更新損失值和模型參數
def train(total_loss, global_step):
lr = tf.train.exponential_decay(0.01, global_step, decay_steps=350, decay_rate=0.1, staircase=True)
# 採用滑動平均的方法更新損失值
loss_averages = tf.train.ExponentialMovingAverage(decay=0.9, name='avg')
losses = tf.get_collection('losses') # losses的列表
loss_averages_op = loss_averages.apply(losses + [total_loss]) # 計算損失值的影子變量op
# 計算梯度
with tf.control_dependencies([loss_averages_op]): # 控制計算指定,只有執行了括號中的語句才能執行下面的語句
opt = tf.train.GradientDescentOptimizer(lr) # 創建優化器
grads = opt.compute_gradients(total_loss) # 計算梯度
# 應用梯度
apply_gradient_op = opt.apply_gradients(grads, global_step=global_step)
# 採用滑動平均的方法更新參數
variable_averages = tf.train.ExponentialMovingAverage(0.999, num_updates=global_step)
variables_averages_op = variable_averages.apply(tf.trainable_variables())
with tf.control_dependencies([apply_gradient_op, variables_averages_op]):
# tf.no_op()表示執行完apply_gradient_op, variable_averages_op操作之後什麼都不做
train_op = tf.no_op(name='train')
return train_op
View Code
TensorBoard可視化 summary
############ TensorBoard可視化 summary ############
summary_writer = tf.summary.FileWriter(logdir="./logs", graph=graph) # 創建事件文件
tf.summary.scalar(name="losses", tensor=total_loss) # 收集損失值變量
tf.summary.scalar(name="acc", tensor=accuracy) # 收集精度值變量
tf.summary.scalar(name='learning_rate', tensor=learning_rate)
merged_summary_op = tf.summary.merge_all() # 將所有的summary合併為一個op
模型保存和恢復 Saver
saver = tf.train.Saver(max_to_keep=5) # 保存最新的5個檢查點
創建會話
配置會話
在創建會話之前我們一般都要配置會話,比如使用GPU還是CPU,用多少GPU等等。
我們一般使用 tf.ConfigProto()配置Session運行參數&&GPU設備指定
config = tf.ConfigProto(allow_soft_placement=True, log_device_placement=True)
config.gpu_options.per_process_gpu_memory_fraction = 0.4 # 佔用40%顯存 sess = tf.Session(config=config)
# 或者
config = tf.ConfigProto()
config.allow_soft_placement = True
config.log_device_placement = True
with tf.Session(config=config) as sess:
# 或者
sess = tf.Session(config=config)
tf.ConfigProto(log_device_placement=True):記錄設備指派情況
設置tf.ConfigProto()中參數log_device_placement = True,獲取 operations 和 Tensor 被指派到哪個設備(幾號CPU或幾號GPU)上運行,會在終端打印出各項操作是在哪個設備上運行的。
tf.ConfigProto(allow_soft_placement=True):自動選擇運行設備
在TensorFlow中,通過命令 “with tf.device(‘/cpu:0’):“,允許手動設置操作運行的設備。如果手動設置的設備不存在或者不可用,就會導致tf程序等待或異常,為了防止這種情況,可以設置tf.ConfigProto()中參數allow_soft_placement=True,自動選擇一個存在並且可用的設備來運行操作。
config.gpu_options.allow_growth = True
當使用GPU時候,Tensorflow運行自動慢慢達到最大GPU的內存
tf.test.is_built_with_cuda():返回是否能夠使用GPU進行運算
為了加快運行效率,TensorFlow在初始化時會嘗試分配所有可用的GPU顯存資源給自己,這在多人使用的服務器上工作就會導致GPU佔用,別人無法使用GPU工作的情況。這時我們需要限制GPU資源使用,詳細實現方法請參考我的另一篇博客 tensorflow常用函數 Ctrl+F搜索“限制GPU資源使用”
創建會話Session
Session有兩種創建方式:
sess = tf.Session(config=config, graph=graph)
# 或通過with的方式創建Session
with tf.Session(config=config, graph=graph) as sess:
如果我們之前自定義了graph,則在會話中也要配置graph,如果之前沒有自定義graph,使用的是tensorflow默認graph,則在會話不用自己去定義,tensorflow會自動找到默認圖。
在訓練模型之前我們首先要設置一個高級一點的東西,那就是檢查是否有之前保存好的模型,如果有着接着前面的繼續訓練,如果沒有則從頭開始訓練模型。
恢復/重新訓練
定義一個檢查模型是否存在的函數,為了美觀,可以把這個函數放在最上面,或者其他腳本中,通過import導入。
def load_model(sess, saver, checkpoint_dir):
"""加載模型,看看還能不能加一個功能,必須現在的檢查檢點是1000,但是我的train是100,要報錯
還有就是讀取之前的模型繼續訓練的問題
checkpoint_dir = checkpoint"""
# 通過checkpoint找到模型文件名
ckpt = tf.train.get_checkpoint_state(checkpoint_dir=checkpoint_dir)
if ckpt and ckpt.model_checkpoint_path:
ckpt_name = os.path.basename(ckpt.model_checkpoint_path) # 返回最新的chechpoint文件名 model.ckpt-1000
print("新的chechpoint文件名", ckpt_name) # model.ckpt-2
saver.restore(sess, os.path.join(checkpoint_dir, ckpt_name))
# 現在不知道checkpoint文件名時怎樣的,因此不知道裏面如何運行
counter = int(next(re.finditer("(\d+)(?!.*\d)", ckpt_name)).group(0)) # 2
print(" [*] 成功模型 {}".format(ckpt_name))
return True, counter
else:
print(" [*] 找不到checkpoint")
return False, 0
View Code
如果大家之前用的是global_step = tf.Variable(0, trainable=False),則使用下面diamante
# 加載模型,如果模型存在返回 是否加載成功和訓練步數
could_load, checkpoint_step = load_model(sess, saver, "./log")
if could_load:
print(" [*] 加載成功")
else:
print(" [!] 加載失敗")
try:
tf.global_variables_initializer().run()
except:
tf.initialize_all_variables().run()
如果大家想使用step=0,step+=1,則可以使用下面代碼
# 加載模型,如果模型存在返回 是否加載成功和訓練步數
could_load, checkpoint_step = load_model(sess, saver, FLAGS.checkpoints_dir)
if could_load:
step = checkpoint_step
print(" [*] 模型加載成功")
else:
print(" [!] 模型加載失敗")
try:
tf.global_variables_initializer().run()
except:
tf.initialize_all_variables().run()
step = 0
開始訓練
for epoch in range(epochs):
for i in range(batch_nums):
start_time = time.time()
# batch_images = data_X[i * batch_size:(i + 1) * batch_size]
# batch_labels = data_y[i * batch_size:(i + 1) * batch_size]
train_batch_x, train_batch_y = mnist.train.next_batch(batch_size)
# 使用真實數據填充placeholder,運行訓練模型和合併變量操作
_, summary, loss, step = sess.run([train_op, merged_summary_op, total_loss, global_step],
feed_dict={inputs: train_batch_x,
labels: train_batch_y,
keep_prob: 0.5})
if step % 100 == 0:
summary_writer.add_summary(summary, step) # 將每次迭代后的變量寫入事件文件
summary_writer.flush() # 強制summary_writer將緩存中的數據寫入到日誌文件中(可選)
############ 可視化打印 ############
print("Epoch:[%2d] [%4d/%4d] time:%4.4f,loss:%.8f" % (
epoch, i, batch_nums, time.time() - start_time, loss))
# 打印一些可視化的數據,損失...
if step % 100 == 0:
acc = sess.run(accuracy, feed_dict={inputs: mnist.validation.images,
labels: mnist.validation.labels,
keep_prob: 1.0})
print("Epoch:[%2d] [%4d/%4d] accuracy:%.8f" % (epoch, i, batch_nums, acc))
############ 保存模型 ############
if acc > max_acc:
max_acc = acc
save_path = saver.save(sess,
save_path=os.path.join(checkpoints_dir, "model.ckpt"),
global_step=step)
tf.logging.info("模型保存在: %s" % save_path)
print("優化完成!")
模型評估
eval.py
模型評估的代碼和模型訓練的代碼很像,只不過不需要對模型進行訓練而已。
from ops import *
import tensorflow as tf
from nets.my_alex import alexNet
from tensorflow.examples.tutorials.mnist import input_data
tf.flags.DEFINE_integer('batch_size', 50, 'batch size, default: 1')
tf.flags.DEFINE_integer('class_num', 10, 'batch size, default: 1')
tf.flags.DEFINE_integer('epochs', 10, 'batch size, default: 1')
tf.flags.DEFINE_string('checkpoints_dir', "checkpoints", '保存檢查點的地址')
FLAGS = tf.flags.FLAGS
# 從MNIST_data/中讀取MNIST數據。當數據不存在時,會自動執行下載
mnist = input_data.read_data_sets('./data', one_hot=True, reshape=False)
# 將數組張換成圖片形式
print(mnist.train.images.shape) # 訓練數據圖片(55000, 28, 28, 1)
print(mnist.train.labels.shape) # 訓練數據標籤(55000, 10)
print(mnist.test.images.shape) # 測試數據圖片(10000, 28, 28, 1)
print(mnist.test.labels.shape) # 測試數據圖片(10000, 10)
print(mnist.validation.images.shape) # 驗證數據圖片(5000, 28, 28, 1)
print(mnist.validation.labels.shape) # 驗證數據圖片(5000, 10)
def evaluate():
batch_size = FLAGS.batch_size
batch_nums = mnist.train.images.shape[0] // batch_size # 一個epoch中應該包含多少batch數據
class_num = FLAGS.class_num
test_batch_size = 5000
test_batch_num = mnist.test.images.shape[0] // test_batch_size
############ 保存檢查點的地址 ############
checkpoints_dir = FLAGS.checkpoints_dir # checkpoints
# 如果檢查點不存在,則創建
if not os.path.exists(checkpoints_dir):
print("模型文件不存在,無法進行評估")
######################################################
# 創建圖 #
######################################################
graph = tf.Graph() # 自定義圖
# 在自己的圖中定義數據和操作
with graph.as_default():
inputs = tf.placeholder(dtype="float", shape=[None, 28, 28, 1], name='inputs')
labels = tf.placeholder(dtype="float", shape=[None, class_num], name='labels')
############ 搭建模型 ############
logits = alexNet(inputs, FLAGS.class_num, keep_prob=1) # 使用placeholder搭建模型
############ 模型精度 ############
predict = tf.argmax(logits, 1)
accuracy = tf.reduce_mean(tf.cast(tf.equal(predict, tf.argmax(labels, 1)), tf.float32))
############ 模型保存和恢復 Saver ############
saver = tf.train.Saver(max_to_keep=5)
######################################################
# 創建會話 #
######################################################
config = tf.ConfigProto(allow_soft_placement=True, log_device_placement=True)
with tf.Session(config=config, graph=graph) as sess:
# 加載模型,如果模型存在返回 是否加載成功和訓練步數
could_load, checkpoint_step = load_model(sess, saver, FLAGS.checkpoints_dir)
if could_load:
print(" [*] 加載成功")
else:
print(" [!] 加載失敗")
raise ValueError("模型文件不存在,無法進行評估")
for i in range(test_batch_num):
test_batch_x, test_batch_y = mnist.test.next_batch(test_batch_num)
acc = sess.run(accuracy, feed_dict={inputs: test_batch_x,
labels: test_batch_y})
print("模型精度為:", acc)
one_image = mnist.test.images[1].reshape(1, 28, 28, 1)
predict_label = sess.run(predict, feed_dict={inputs: one_image})
# print("123", tf.argmax(pre_yyy, 1).eval()) # [7]
# print("123", tf.argmax(yyy, 1).eval()) # 7
def main(argv=None):
evaluate()
if __name__ == '__main__':
tf.app.run()
參考文獻
CSDN_AlexNet神經網絡結構
CSDN_【深度學習理論3】ALexNet模型的詳解
github搜索tensorflow AlexNet
github_finetune_alexnet_with_tensorflow
github_AlexNet_with_tensorflow
github tensorflow vgg
ResNet詳解與分析
tensorflow中使用tf.ConfigProto()配置Session運行參數&&GPU設備指定
比較完整且容易入門的MNIST案例
本站聲明:網站內容來源於博客園,如有侵權,請聯繫我們,我們將及時處理
※台中搬家遵守搬運三大原則,讓您的家具不再被破壞!
台中搬家公司推薦超過30年經驗,首選台中大展搬家
